LB-SERIES™
duroplastische beschichtungen
OVERVIEW
Niedrigtemperatur-Pulverbeschichtungen
Manufacturers recognize the impact that product materials and processes, including coating finishes, have on energy consumption and the environment. Businesses are also aware of the impact of rising energy prices and the challenges of ongoing availability and supply, which means finding new ways of working in a world that cares more about its future.
LB-SERIES™ is a specially formulated thermoset powder coating solution that reduces baking temperature and curing time, thereby consuming less energy and accelerating production.
LB-SERIES™ is a unique system where curing temperatures are roughly 20 to 30°C lower (between 140°C and 170°C), cutting energy consumption and costs up to 25%. Adapting LB-SERIES™ also improves productivity with an average 20% faster cure time.
MAIN FEATURES
- Significantly less energy consumption translates to energy cost savings.
- Lower impact on the environment, supporting corporate sustainability objectives.
- Increased line productivity and time savings, creating greater efficiencies and delivering lower costs.
- No compromise on the physical or chemical properties of the current coating formulation.
- A broad range of stock colors and textures are readily available.
- Free cost-saving calculations are available through our experts.
- Can be combined with some other Protech Group coating features.
PROVEN PERFORMANCE
| PRE-TREATMENT | For steel and Aluminum–Phosphating or Zirconium, Media blast or other suitable surface treatment |
| APPLICATION CONDITIONS | Electrostatic powder spray 40 to 100 kv |
| FILM THICKNESS | For normal usage 3.0 to 8.0 mils (Color and finish type related) |
| HARDNESS | HB to 4H (Formulation related) |
| SPECIFIC GRAVITY | 1.2 to 1.75 (Color related) |
| COVERAGE | 160 to 110 ft² / lbs / mil at 100% efficiency (Color related) |
| BAKING SCHEDULE | METAL TEMPERATURE (Formulation Related) 8-10 minutes at 280ºF (138ºC) Super low-temperature cure 8-10 minutes at 320ºF (160ºC) Low-temperature cure 2-6 Minutes at 400 (205ºC) Fast Cure |
COLOR OPTIONS
Custom formulations
Talk to your coating expert regarding custom formulations to fit your exact needs.
Stock colors
Select one of the many stock colors that are readily available for processing.
Color reference chart
Get inspired by a broad range of standard colors. Request a RAL fan deck or ask one of our experts.
RESOURCES
Troubleshooting
We stand by our products, even when things don’t go quite as planned. From cleaning and phosphating all the way to the final cured film appearance, we are here to help address your issues with proven solutions.
Contact our experts for tailored support.
Care and maintenance
To ensure the life of your asset is maximized, a simple and regular maintenance program should be implemented.
Contact our experts for specific tips and advice on cleaning.
Compliance
LB-SERIES™ formulations can also contribute to sustainable building certifications and credits including LEED, BREEAM, and more.
Ask our experts to see what different types of compliance, certification, or accreditation are available in your area.
LB-SERIES™ can be formulated to be compliant with certain guidelines, including QUALICOAT standards.
